TRD-N1000-RZV
TRD-N1000-RZV

TRD-N1000-RZV Rotary Encoder, Shaft 8mm.,1000P/R,5DC,Line driver

TRD-N1000-RZV

Rotary Encoder
อัตราค่าจัดส่ง

รายละเอียดสินค้า

TRD-N1000-RZV

Encoder Type Incremental
Duty Type Medium
Pulse Per Revolution 1000
Input Voltage (VDC) 5
Output Form Line Driver (Differential - 26C31)
Signal Format Quadrature (2-Phase Output) + Home Position
Output From Side
Shaft Solid
Shaft Diameter (mm) 8
Diameter (mm) 50
Depth (mm) 37
Mounting Pitch (mm) 40
Cable Length (meter) 0.50
Connector Type Tinned Ends
Protection Level IP50 (Dust Proof)
Mounting Screws Included
Short Circuit Protection No
Reverse Origin Action Positive Logic (Active High)
Total Shaft Length (mm) 15.0
Usable Shaft Length (mm) 10.0
