SDR-75-12, DIN Rail Power Supply, 88.5%, 12V, 6.3A, 75.6W, Adjustable
SDR-75-12
อัตราค่าจัดส่ง
รายละเอียดสินค้า
SDR-75-12, DIN Rail Power Supply, 88.5%, 12V, 6.3A, 75.6W, Adjustableข้อมูลสินค้า
SDR-75-12 MEAN WELL
SDR-75-24 MEAN WELL
SDR-75-48 MEAN WELL
SDR-120-12 MEAN WELL
SDR-120-24 MEAN WELL
SDR-120-48 MEAN WELL
SDR-240-24 MEAN WELL
SDR-240-48 MEAN WELL
SDR-480-24 MEAN WELL
SDR-960-24 MEAN WELL
SDR-960-48 MEAN WELL
SDR-480P-24 MEAN WELL
SDR-480P-48 MEAN WELL
SDR-480 Series Features:
Built-in active PFC function, PF>0.93
High efficiency up to 94%
Protections: Short circuit / Overload / Over voltage / Over temperature
Other features:
- Universal AC input / Full range
- Can be installed on DIN rail TS-35 / 7.5 or 15
- Cooling by free air convection
- UL508(industrial control equipment) approved
- EN6100-2( EN50082-2) industrial immunity level
- Built-in DC OK relay contact
- 150% peak load capacity
- Comply with GL and SEMI f47
- 3 years warranty
| Wattage | 480 | 480 |
| Input Voltage | 90~264VAC, 127~370VDC | 88~264VAC, 124~370VDC |
| Output Current | 0~10 | 0~10 |
| Output Voltage | 24 | 48 |
| Output Voltage Options | Single | Single |
| DC output adjustment | 24-28V | 48-55V |
| Dimensions | 85.5 x 125.2 x 128.5 | 85.5 x 125.2 x 128.5 |
| Working Temperature | -25~+70°C | |
| Safety Standards | UL508, TUV EN60950-1, GL approved | |
| EMC Standards | Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), EN61204-3, Heavy industry level, SEMI F47, GL | |
