HMI with external touchscreen,1080p HDMI

Model

cMT-FHDX-820

cMT-SVRX-820 / 822

Memory

Flash

RAM

4 GB

1 GB

4 GB

1 GB

Processor

Quad-core RISC

Quad-core RISC

I/O Port

SD Card Slot USB Host Ethernet

COM Port

HDMI

Recommended Resolutions

(Please use these recommended screen resolutions to avoid compatibility issues.)

Audio Output

N/A

Micro SD x1

USB 2.0 x 1

USB 2.0 x 1

LAN 1: 10/100/1000 Base-T x 1

LAN 1: 10/100/1000 Base-T x 1

LAN 2: 10/100 Base-T x 1

LAN 2: 10/100 Base-T x 1

COM1: RS-232 2W

COM1: RS-232 2W

COM2: RS-485 2W/4W

COM2: RS-485 2W/4W

COM3: RS-485 2W

COM3: RS-485 2W

Customizable

N/A

(max. resolution 1920 x 1080)

720x480 / 720x576 / 800x600

1024x768 / 1280x720

N/A

1366x768 / 1920x1080

HDMI Audio Output

N/A

RTC

Built-in

Built-in

Power

Input Power

24±20%VDC

24±20%VDC

Power Isolation

Built-in

Built-in

Power Consumption

850mA@24VDC

850mA@24VDC

Voltage Resistance

500VAC (1 min.)

500VAC (1 min.)

Isolation Resistance

Exceed 50MΩ @ 500VDC

Exceed 50MΩ @ 500VDC

Specification

PCB Coating

Yes

Yes

Enclosure

Plastic

Plastic

Dimensions WxHxD

29.8 x 130 x 115 mm

29.8 x 130 x 115 mm

Weight

Approx. 0.24 kg

Approx. 0.24 kg

Mount

35 mm DIN rail mounting

35 mm DIN rail mounting

Environment

Protection Structure Storage Temperature

Operating Temperature

Relative Humidity

Vibration Endurance

IP20

IP20

-20° ~ 60° C (-4° ~ 140° F)

-20° ~ 60° C (-4° ~ 140° F)

0° ~ 50° C (32° ~ 122° F)

0° ~ 50° C (32° ~ 122° F)

10% ~ 90%

10% ~ 90%

(non-condensing)

(non-condensing)

10 to 25Hz

10 to 25Hz

(X, Y, Z direction 2G 30 minutes)

(X, Y, Z direction 2G 30 minutes)

Certificate

CE

UL

CE marked

cULus Listed

CE marked

cULus Listed

Software

Weincloud

EasyAccess 2.0 (Optional) Dashboard (Optional)

EasyAccess 2.0 (Optional) Dashboard (Optional)

EasyAccess 2.0 (Built-in) Dashboard (Optional)

CODESYS

Optional

Optional
